Mini Cement Mixer Rated Overload Concrete Mixer for Cast Iron CogWheel and Rubber Wheels

1 set
MOQ
$120/set
Price
Mini Cement Mixer Rated Overload Concrete Mixer for Cast Iron CogWheel and Rubber Wheels
Features Gallery Product Description Request A Quote
Features
Specifications
Engine: Motor 220V/380V50HZ/60HZ,Diesel KAMA178
Power: 2.2KW,4KW
Ratation Speed: 2000r/min,3000r/min
Feed Capacity: 350L
Discharge Capacity: 280L
Productivity: 8-10m3/h
Weight: 285kgs
Dimension: 195*94*177cm
Basic Infomation
Place of Origin: Ningbo,China
Brand Name: YONGTUO
Certification: CE,SGS
Model Number: YT
Payment & Shipping Terms
Packaging Details: nude package or up to the customers
Delivery Time: 10 days
Payment Terms: TT or L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 100 sets/month
Product Description

Mini Cement Mixer Rated Overload Concrete Mixer for Cast Iron CogWheel and Rubber Wheels





YT  Series Small Concrete Mixer,120L mini concrete mixer,140L,160L and 180L concrete mixer


Description of YT Series Small Concrete Mixer:

YT series portable concrete mixer is mainly used in the field of small-scale architecture and decoration for mixing mortar, mixing chemical and feed etc. It is easy to move and have a small volume, with such merits as rapid mixing rate and high quality, and so on.

Voltage:110V/220V/380V
Power:Electirc motor 4.4kw
Mixed Batch output:90L-260L
Drum Volume:120L-350L
Dimension:81*71*38cm,190*120*140cm


High quality provides maximum customer benefits!!! Hot Sale!!!

Portable Concrete Mixer without Hopper

Advantages
1.Hand-fed concrete mixers from 80-260L litres mixed batch output
2.All models capable of mixing at a rate of 32 batches per hour giving production output rates ranging 4 cubic metres per hour
3.Robustly engineered with fully enclosed drivelines, Topmac mixers provide safe, reliable performance and long service life
4.Positive, heavy duty driveline using Belt driver; bevel wheel and pinion.
5.Highly efficient, two piece heavy gauge, steel drum
6.Multi-position lockable drum
7.Fast Tow trailer models available with adjustable towbar, pneumatic tyres, mudguards and independent suspension

can make as your designs,welcome OEM!



Specification
MODEL NO. FC260L FC300L FC350L FC400L FC450L FC500L FC600L FC700L FC800L
Feel Capacity 260L 300L 350L 400L 450L 500L 600L 700L 800L
Discharge Capacity 180L 220L 270L 320L 370L 420L 520L 620L 720L
Drum Mouth 450mm 450mm 516mm 516mm 516mm 566mm 566mm 600mm 600mm
Drum Max Dia. 700m 700mm 800mm 800mm 800mm 900mm 900mm 1000mm 1000mm
Drum Height 687mm 777mm 766mm 851mm 936mm 920mm 1040mm 075mm 1205mm
RPM of Drum 18 20 20 20 20 17 17 17 17
Lower Drum Thickness 4mm
Upper Drum Thickness 3mm
Productivity 6-10m3/h 8-12m3/h 10-14m3/h 12-16m3/h 14-18m3/h 16-20m3/h 20-24m3/h 24-28m3/h 28-32m3/h
Diesel Engine 4HP 4HP 6HP 6HP 6HP 9HP 9HP 9HP 9HP
Gasoline Engine 4.5HP 4.5HP 6.5HP 6.5HP 6.5HP 9HP 9HP 9HP 9HP
Electric Motor 1.5KW 1.5KW 2.2KW 2.2KW 2.2KW 3KW 3KW 3KW 3KG
Net Weight 260KG 280KG 300KG 340KG 350KG 360KG 380KG 490KG 500KG




Model YT80 YT100 YT120 YT130
Capacity 80L 100L 120L 130L
Power 550W 550W 550W 550W
Voltage 110V/220V/380V 110V/220V/380V 110V/220V/380V 110V/220V/380V
Motor Speed 2800RMP 2800RMP 2800RMP 2800RMP
Overall Dimensions 123*67*125CM 123*67*125CM 130*71*133CM 130*71*133CM
Weight 62KGS 64KGS 66KGS 68KGS




Mini Cement Mixer Rated Overload Concrete Mixer for Cast Iron CogWheel and Rubber Wheels 0Mini Cement Mixer Rated Overload Concrete Mixer for Cast Iron CogWheel and Rubber Wheels 1Mini Cement Mixer Rated Overload Concrete Mixer for Cast Iron CogWheel and Rubber Wheels 2





You may interested in other products:concrete vibrator,concrete power trowel
