Product Details:
Payment & Shipping Terms:
|
| Vibrating Frequency: | 220-260HZ | Vibrating Amplitude: | 0.7-1.0mm |
|---|---|---|---|
| Length: | 1m-12m | Dia: | 38mm |
| Weight Of Concrete Vibrator Shaft: | 7 Kgs | Overall Dimension: | 1376*80*138mm |
Rubber Hose Rubber Pipe Tube industrial hydraulic Fittings Coupling with steel
1.Japanese type vibrator shaft,
2,Korean type vibrator shaft ,
3.Dynapac type vibrator shaft,
4.Chinese type vibrator shaft,
38mm diameter concrete vibrator shaft with butterfly/Janpanese type
concrete poker vibrator shaft
vibrator poker shafts
Electric motor concrete vibrator shaft
We are an expert manufacturer of concrete vibrators,the concrete could match flexible shafts and flexible tubes.
rich expertise and advanced manufacturing equipments ensures the reliable quality, which being sold to all over China and exported to many countries including Europe, Japan, Korea , and Malaysia etc.
| Model | ZN25 | ZN35 | ZN38 | ZN50 | ZN70 |
| Vibrating Head Diameter(mm) | 25 | 35 | 38 | 50 | 70 |
| Vibrating Frequency(Hz) | 220 | 200 | 200 | 200 | 200 |
| Vibrating Amplitude(mm) | 0.7 | 0.9 | 1.0 | 1.0 | 1.2 |
| Motor Speed(r/min) | 4000 | 4000 | 4000 | 4000 | 4000 |
| Length(m) | 4-12 | 4-12 | 4-12 | 4-12 | 4-12 |
| Weight(kg) | 6 | 9 | 11.5 | 12.5 | 14 |
Hydraulic Industrial Hose Structure
Consists of an inner tube, middle layer, two, four or six spiral wire reinforcements and cover.
Inner tube is to transmit liquid under pressure and protect steel wire against corrosion
Reinforcement: four or six plies steel wire reinforced .
cover is to protect wire against damage.
Application:
High pressure wire reinforcement hydraulic hose mainly used in mine hydraulic support, oil exploration, suitable to engineer construction, and in industry department mechanization and automatic hydraulic systems.
